Cooler Master Elite V3 400W Intel ATX 12V V2.31 Power Supply with quiet 120mm Fan
Return & Warranty
No return policy
Change of mind is not applicable
No warranty
100% original product
-->
- ELITE V3 The new Elite V3 power supply is a dependable choice for the everyday PC user. The included 120mm quiet fan, PCI-E support, and global 3 year warranty delivers a PSU that provides function and resilience you can count on. It's the perfect option for users and applications that don't require 80 Plus efficiency to get the job done. This power supply has been engineered for reliability with a focus on reducing random shutdowns in brownout conditions when power sources are unstable. The Elite V3 is a complete solution delivering powerful stability in a small package for an affordable price.
- 75% EFFICIENCY The efficiency of your power supply unit is important because it directly affects you system's performance and your power bill. The efficiency rating does not reflect the quality or reliability of a PSU. It only reflects the unit's ability...
- Efficiency: 75%Number of
- Fans: 1Input
- Voltage: 120
- V ACInput Voltage: 230 V ACNumber of +12V
- Rails: 1Output
- Voltage: 12 V DC @ 30
- AOutput Voltage: 5 V DC @ 14
- AOutput Voltage: 3.3 V DC @ 14
- AOutput Voltage: -12 V DC @ 300 mAOutput
- Voltage: 5 V @ 2.50
- AOutput Power: 400
- WForm Factor:
- InternalHeight: 3.4W
- idth: 5.9"D
- epth: 5.5"E nvironmentally
- Friendly: YesEnvironmental
- Certification: cTUVusEnvironmental
- Certification: TEnvironmental
- Certification: WEEE
- Environmental Certification: China
| LEARN MORE ABOUT THE COOLER MASTER MPW-4001-ACAAN1-US | |
|---|---|
| Brand | Cooler Master |
| Series | Elite V3 400W |
| Model | MPW-4001-ACAAN1-US |
| Details | |
| Type | Intel ATX 12V V2.31 |
| Maximum Power | 400W |
| Fans | 1 x 120mm fan |
| PFC | Active |
| Main Connector | 20+4Pin |
| +12V Rails | Single |
| PCI-Express Connector | 1 x 6+2-Pin |
| SATA Power Connector | 6 |
| Power Good Signal | 100-500ms |
| Hold-up Time | >10ms at 100% Load |
| Efficiency | 75% @ Typical Load |
| Over Voltage Protection | Yes |
| Input Voltage | 100 - 240 V |
| Input Frequency Range | 50/60 Hz |
| Input Current | 8A - 4A |
| MTBF | +3.3V@14A, +5V@14A, +12V@30A, -12V@0.3A, +5VSB@2.5A MTBF >100,000 Hours TUV, cTUVus, CE, FCC, BSMI 3.39 |
| Max PSU Length | 140 mm 3.7 |
| Features | |
| Connectors | 1 x M/B 20+4 Pin 1 x CPU 12V 4+4 Pin 6 x SATA 3 x Peripheral 4 Pin 1 x FDD Cable 4 Pin 1 x PCI-e 6+2 Pin |
| Features | Active PFC + Forward Topology Design - Constructed with protective measures normally found in high-end power supplies to increase safety and current stability. Higher Temperature Resistance - Capable of operating at 40°C under full load allowing longer lifespan in warmer environments. Peak Power Tolerance - Can reliably push an additional 50W at peak power load for up to 10 seconds. 75% efficiency - Maintains an average efficiency of 75% at 50% load. Super Resilient - The Elite V3 will perform consistently in whatever environment you throw at it whether it's high altitudes above 5000 meters or ultra humid settings like a tropical rain-forest. |
| Warranty Information | |
| Manufacturing Warranty | 01 Year Warranty |
